| IR Night Vision |
5 m (16 ft) |
| Resolution |
Main camera: 12MP
Package camera: 8MP |
| UniFi Application Suite |
Protect, Access |
| Weatherproofing |
IP55 |
| Tamper Resistance |
IK07
LCM IK04 |
| Audio |
Two-way audio |
| UL 294 Level |
Destructive attack: Level I
Line security: Level I
Endurance: Level I
Standby power: Level I |
| NDAA Compliant |
Yes |
| Enclosure Material |
Aluminum |
| Mount Material |
Wall mount: Stainless steel
Gangbox mount plate: SGCC steel
Gangbox mount cover: Polycarbonate
Wedge mount: Aluminum |
| Mounting |
Wall mount, Gangbox mount plate, 20° wedge mount (Included)
Junction box (Optional) |
| Networking Interface |
GbE RJ45 port |
| Connectivity |
BLE 4.1
NFC |
| Power Method |
PoE+
UL 294 Power-limited Class 2 PSU
UL 60950-1/62368-1 LPS/PS2 PSU |
| Max. Power Consumption |
18W |
| Supported Voltage Range |
42–57V DC |
| Image Settings |
Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay, HDR |
| Max. Frame Rate |
Main camera: 12MP, 20 FPS or 8MP, 30 FPS
Package camera: 3 FPS |
| Resolution |
Main camera: 12MP, 3024 x 4096 (3:4) or 8MP, 2160 x 3840 (9:16)
Package camera: 8MP, 3264 x 2448 (4:3) |
| Field of View |
Main camera:
H: 100°, V: 136.3°, D: 176.4° (12MP)
H: 70.9°, V: 127.5°, D: 147.4° (8MP)
Package camera:
H: 66°, V: 51.7°, D: 78° |
| Sensor |
Main camera: 12MP CMOS
Package camera: 8MP CMOS |
| Lens |
Fixed focal length |
| Night Mode |
Built-in IR LED illumination and IR cut filter |
| Display Size |
75 mm (3") diagonal |
| Screen Technology |
Capacitive multi-touch |
| Luminance |
Max. 1000 nits (Typical) |
| Screen Orientation |
Portrait |
| Display Resolution |
480 x 854 px |
| LEDs |
R/G/B/W/Amber |
| Button |
(1) Ring button
(1) Factory reset
(1) Tamper switch |
| Processor |
Quad core Arm® Cortex®-A53 based chip |
| Certifications |
CE, FCC, IC, UL 294, CAN/ULC-60839-11-1 |
| PoE Cabling Requirements |
Cat 5e cabling is the minimum performance category recommended. The performance category utilized should match the transmission speed required at the installation site.
The minimal conductor gauge permitted to connect between the PSE or power injector and the PD shall be 26 AWG (0.13 mm²) for patch cords; 24 AWG (0.21 mm²) for horizontal or riser cable. |
| UL 294 Statement |
Compliance with IEEE 802.3 specifications was not verified as part of UL 294.
The equipment is intended to comply with the section of the National Electrical Code, ANSI/NFPA 70, Article 725.121, Power Sources for Class 2 and Class 3 Circuits. |
| Ambient Operating Temperature |
Device: -30 to 50° C (-22 to 122° F)
Display: -25 to 50° C (-13 to 122° F) |
| Ambient Operating Humidity |
5 to 90% noncondensing |
