| Video Resolutions | Up to 4K 60Hz 4:4:4 |
| Vesa Resolutions | Up to DCI 4K (4096X2160) |
| HDR Formats/Resolutions | 420, 422, 444, (10 and 12 deep color) HDR10, HDR10+, HLG |
| Color Space | YUV (Component), RGB (CSC:REC. 601, REC. 709, BT2020, DCI, P3 D6500) |
| Chroma Subsampling | 4:4:4, 4:2:2, 4:2:0 Supported |
| Deep Color | Up to 16 bit (1080), up to 12 bit (4K) |
| Audio Formats Supported HDMI | PCM 2.0CH, LPCM 5.1 and 7.1, Dolby Digital, DTS 5.1, Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio, DTS-X, Dolby Atmos |
| Audio Formats Supported Extracted (2CH Port) | PCM 2 CH (No Downmix) |
| HDBASET (CAT) Distance (4K) | 230 feet |
| HDBASET (CAT) Distance (Full HD) | 330 feet |
| HDMI Lead Out (Up to 4K60 4:4:4) | Up to 50 feet (Using bullet train HDMI) |
| HDMI Lead Out (W/AOC Cable) (Up to 4K60 4:4:4) | Up to 130 feet (Using bullet train AOC) |
| Bandwidth | 18 GBPS (W/ICT) |
| HDCP | HDCP 2.2 and earlier |
| HDMI | Type A |
| Audio (Extracted Analog) | 3 Pin Terminal Block (Unbalanced) Each |
| IR RX | 3.5mm Stereo (3 Conductor) Each |
| RS232 | 3 Pin Terminal Block Each |
| Power | 2 Pin Terminal Block Each |
| Power Consumption (Total) | 9 watts max pair |
| Power Supply | Input-AC 100-240V~50/60 Hz / Output-DC 48V .5A (wall version) |
