| Screen Size |
75" (Also available in 65", 85", and 115") |
| VESA® Hole Pitch (W x H) |
300 x 300 mm / 11 7/8" x 11 7/8"
|
| Video Processing |
XR Clear Image |
| Motion enhancer |
XR Motion Clarity |
| 4K Processor |
XR Processor |
| HDR (High Dynamic Range) compatiblity |
Yes(HDR10,HLG,Dolby Vision) |
| TRILUMINOS |
RGB Triluminos Max |
| Smoothing |
Smooth Color Gradation |
| Digital Audio Output(s) |
1(Side / Hybrid with Digital Audio Output) |
| Speaker type |
Acoustic Mulit -Audio + |
| Speaker Configuration |
Subwoofer x 2, Full Range x 8, Tweeter x 2 |
| Display resolution (H x V, pixels) |
3840 x 2160 |
| Display Type |
RGB LED |
| TV System (Digital Terrestrial) |
ATSC/ ATSC3.0(NEXTGEN TV) depending on your country/area selection |
| Operating System |
Google TV |
| Features specified in HDMI2.1 |
4K120/eARC/VRR/ALLM |
| DTS audio format support |
DTS Digital Surround, DTS Express, DTS-HD Master Audio, DTS-HD High Resolution Audio, DTS:X |
| Dolby audio format support |
Dolby Audio, Dolby Atmos |
| Power Requirements (voltage) |
AC 120V for UL cUL AC 110-240V for other |
| Power Requirements (frequency) |
60Hz for UL cUL 50/60Hz for other |
| Motion enhancer (Native Hz) |
120Hz |
| Picture modes |
Vivid, Standard, Cinema, Professional, Calm, Photo, IMAX Enhanced, Dolby Vision (Vivid/Bright/Dark/Game), FPS game, RTS game |
| Picture processor |
XR Processor |
| HDMI Video Input Signal Format |
4096x2160p (24,60Hz), 3840x2160p (24,30,60,120Hz)*, 1080p (30,60,120Hz), 1080/24p, 1080i (60Hz), 720p (30,60Hz), 720/24p, 480p
*120Hz is supported by HDMI IN 3 and IN 4. |
| HDMI PC Input Signal Format |
640x480 (31.5kHz,60Hz), 800x600 (37.9kHz,60Hz), 1024x768 (48.4kHz,60Hz), 1280x1024 (64.0kHz,60Hz), 1600x900 (55.9kHz,60Hz) |
| Backlight dimming type |
Local Dimming |
| Backlight type |
RGB LED |
| HDCP |
HDCP2.3 (for HDMI1/2/3/4) |
| Number of Tuners (Terrestrial/Cable) |
1 (Digital/Analog) |
| Tuner Channel Coverage (Analog) |
VHF: 2-13/UHF: 14-69/CATV: 1-135 |
| Tuner Channel Coverage (Digital Cable) |
CATV: 1-135 |
| Tuner Channel Coverage (Digital Terrestrial) |
VHF: 2-13/UHF: 14-69 (2-13/14-36 for ATSC3.0) |
| HDMI inputs total |
4(Side) |
| HDMI PC Input Format |
640x480(31.5kHz,60Hz), 800x600(37.9kHz,60Hz), 1024x768(48.4kHz,60Hz), 1280x1024(64.0kHz,60Hz), 1600x900(55.9kHz,60Hz), 1680x1050(65.3kHz,60Hz), 1920x1080(67.5kHz,60Hz) |
| Bluetooth profile support |
Version 5.3 Subwoofer x 2, Full Range x 2, Tweeter x 2, Beam Tweeter x 2 |
| RF (Terrestrial/Cable) Connection Input(s) |
1(Side) |
| USB ports |
2(Side) |
| Ethernet inputs |
1(Side) |
| RS-232C Input(s) |
1(Side) |
| Wi-Fi Standard |
Wi-Fi 6E |
