Standards| IEEE 802.3af (Power over Ethernet) | | | IEEE 802.3at (High-Power PoE+ Power over Ethernet) | | | IEEE 802.3 (10Base-T Ethernet) | | | IEEE 802.3ab (Gigabit Ethernet) | | | IEEE 802.3u (100Base-TX Fast Ethernet) | |
|
Media support| 100Base-TX Cat5 UTP/STP RJ45, 8 pin | | | 1000Base-T Cat5e UTP/STP RJ45, 8 pin | |
|
| Ports | | 1 RJ45 10/100/1000 Mbps input port for 48V IEEE 802.3af/at-compliant signal | | 1 RJ45 10/100/1000 Mbps PoE output port | |
|
Max PD output power| 24.6 W when using one PoE extender @ 200 m (656 ft.) combined cable length | | | 20 W when using two PoE extenders @ 300 m (984 ft.) combined cable length | | | 16.2 W when using three PoE extenders @ 400 m (1312 ft.) combined cable length | | | 12.5 W when using four PoE extenders @ 500 m (1640 ft.) combined cable length | | | 8.6 W when using five PoE extenders @ 600 m (1968 ft.) combined cable length | |
|
