| Video Resolutions | Up to 4k 60HZ 4:4:4 |
| VESA Resolutions | Up to DCI 4k (4096x2160) |
| HDR Formats/Resolutions | 420, 422, 444 (10 and 12 Deep Color) HDR10, HDR10+, Dolby Vision, HLG |
| Scalers (HDMI) Per Output Optional | 1080P to 4k Up-Scaling (resolutions only, framerate stays the same) |
| Scalers (HDBaseT) Per Output Optional | 4k to 1080P Down-Scaling (resolutions only, framerate stays the same) |
| Audio Formats Supported | HDMI PCM 2.0 Ch, LPCM 5.1 & 7.1, Dolby Digtal, DTS 5.1, Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio, DTS-X, Dolby Atmos |
| Audio Formats Supported Extracted (TOSLINK) | Always down-mixed to 2ch. |
| Audio Formats Supported Extracted (2CH Port) | Always down-mixed to 2ch. |
| Audio Extraction Location | Bind to INPUT, Bind to OUTPUT, or Matrix (Independent) |
| HDBaseT OUT (4K60 4:4:4 & HDR) W/AC-EX70-444-RNE | 70 Meters / 230 Feet (CAT 6a) |
| HDBaseT OUT (1080P) W/AC-EX70-444-RNE | 100 Meters / 330 Feet (CAT 6a) |
| HDBaseT OUT (4K60 4:2:0 MAX) W/AC-EX70-UHD-R | 40 Meters / 131 Feet (CAT 6a) |
| HDBaseT OUT (1080P) W/AC-EX70-UHD-R | 70 Meters / 230 Feet (CAT 6a) |
| HDMI IN/OUT (4K60 4:4:4) | Up to 50 Feet (Using Bullet Train HDMI) |
| HDMI IN/OUT (W/ AOC Cable) (4k60 4:4:4) | Up to 130 Feet (Using Bullet Train AOC) |
| Bandwidth | HDMI 18 GBPS Uncompressed |
| Bandwidth HDBaseT | 18 GBPS (Uses ICT Above 10.2 GBPS Signals) |
| HDCP | HDCP 2.2 and Earlier |
| POH For Receivers (No need to power receivers) | All outputs |
| HDMI Type | A |
| HDBaseT | RJ45 W/ POH for HDBaseT Receivers |
| LAN | RJ45 w/ Web Interface/ Control |
| Audio (Extracted Digital) | Toslink |
| Audio (Extracted Analog) | 5 PIN Terminal Block (Balanced) |
| IR | 3.5MM Stereo (3 Conductor) |
| RS232 | 3 Pin Terminal Block |
