Wavenet CAT5E Direct Burial SOLID 350MHZ 1,000' REEL(black)

Name: Wavenet CAT5E Direct Burial SOLID 350MHZ 1,000' REEL(black)
SKU: 5ESOSPBK2
Availability: InStock

MSRP: $394.00

Manufacturer: Wavenet

SKU: 5ESOSPBK2

Ethereal 8-Pin Cat 5 RJ45 Crimp Connector (50 pk)

C5T

Ethereal 8-Pin Cat 5 RJ45 Crimp Connector (50 pk)

MSRP: $23.99

Ethereal Dual Modular Crimping Tool

CS-CRIMPTOOL

Ethereal Dual Modular Crimping Tool

MSRP: $42.99

Overview
Specifications

Features

Meets or exceeds TIA-568-C.2
RoHS compliant
ATM 155 Mbps
Ethernet 10BASE-T, 100BASE-TX, 100BASE-VG, 100BASE-T4

What’s in the Box

WaveNet CAT5E Direct Burial SOLID 350MHZ 1,000' REEL(black)

Specs

Physical Characteristics

Conductor Material: Solid Annealed Bare Copper
Number of Conductor Pairs: 4
Size: 24 AWG
Stranding: Solid
Insulation Material: HDPE
Average Thickness: 0.0081”
Jacket Material: LDPE
Average Wall Thickness: 0.021”
Nominal Weight: 28 lbs
Shield Material: A1 Foil
Color: Black

Mechanical Characteristics

Temperature Rating (Installation): -40ºC to + 75º C
Temperate Rating (Operating): -40º C to + 75º C
Tensile Strength (before): >=19 Mpa
Elongation (aging): >=300%
Aging Condition (after): >=85% of unaged
Aging Condition (aging): >=50% of unaged

Electrical Characteristics

Max. Conductor DC resistance at 20º C: 9.5Ω/100 Meters
Max. DC Resistance Unbalanced at 20º C: 2.5%
Max. Pair to Pair Ground Capacitance Unbalance: 330 pF/100 Meters
Mutual Capacitance: 5.6 nF/100 Meters
Max. Delay Skew: 45 nS/100 Meters

Dimensions

Size: 1000 Ft

Features

Meets or exceeds TIA-568-C.2
RoHS compliant
ATM 155 Mbps
Ethernet 10BASE-T, 100BASE-TX, 100BASE-VG, 100BASE-T4

What’s in the Box

WaveNet CAT5E Direct Burial SOLID 350MHZ 1,000' REEL(black)
