| Conductor Material (Card Reader Orange) | Stranded Bare Copper |
| AWG | 6C x 22AWG |
| Conductor Diameter | 7/0.24 |
| Insulation Material | Low Smoke FR PVC |
| Average Thickness | 0.200 mm |
| Min. Point Thickness | 0.170 mm |
| Insulation Dia. | 1.15 mm |
| Twisted Pair Dia. | 2.3 mm |
| AL-FOIL | Overlapping>25% |
| Drain Wire | 7 x 0.18 Tinned Copper |
| PE-TAPE | Overlapping>25% |
| Inner Jacket | Low Smoke FR PVC |
| Orange | OD-5.10±0.10 |
| Insulation Colors | White, Green, Red, Black, Orange, Brown |
| Max. Recommended Pulling Tension | 220 N |
| Min Bend Installation | 200 mm |
| Min Bend Installation | 62 mm |
| Storage Temperature Range | -20 ~ +60ºC |
| Installation Temperature Range | -20 ~ +60ºC |
| Operating Temperature Range | 0~+50ºC |
| Test Object | Jacket |
| Test Material | PVC |
| Color | Yellow |
