Wavenet 18/4 PLENUM SHIELDED 1000' REELEX II(white)

Wavenet 18/4 PLENUM SHIELDED 1000' REELEX II(white)
MSRP: $656.00
Manufacturer: Wavenet
SKU: CC1804FPWH4
Features
  • Power-limited control circuits
  • Wiring of the following systems: Security / Audio / Background music
  • Reference Standard: UL 444 / ETL: CL2P/CMP

Specs

Conductor MaterialStranded Bare Copper
AWG18
Conductor7 / 0.4 (mm)
Insulation MaterialFR-PVC
Average Thickness0.200 (mm)
Min. Point Thickness0.170 (mm)
Insulation Diameter (+/0.03mm)1.6
Drain Wire7 / 0.20TC
AL-foil ShieldedYes
Assembly Diameter (+/0.2mm)3.3
Jacket MaterialLow smoke FR-PVC
Average Thickness0.38 (mm)
Min. Point Thickness0.34 (mm)
Outer Diameter (+/0.2mm)3.96
Rip CordYes
Insulation ColorsBlack / Red
Nominal Weight1000ft. / 23.7 lbs.
Capacitance130 Pf/m
DC Resistance (thing/km) Max22.2
Spark Test2.5kv
Dielectric Test2 kv/min
Suggested Voltage Rating300V
Max. Recommended Pulling Tension110 N
Min. Bend Installation35 mm
ColorWhite



Dimensions

Size1000 ft. / Reelex II



Features
  • Power-limited control circuits
  • Wiring of the following systems: Security / Audio / Background music
  • Reference Standard: UL 444 / ETL: CL2P/CMP

}
