Vanco HDMI 4K 4x2 Matrix with Downscaling and ARC HDR HDCP 2

Vanco HDMI 4K 4x2 Matrix with Downscaling and ARC HDR HDCP 2
MSRP: $287.99
Manufacturer: Vanco
SKU: EVMX4K42
Features
  • Allows up to 4 HDMI sources to be distributed simultaneously on 2 displays
  • Supports up to 4K@60Hz and 4:4:4 chroma sampling
  • Supports HDR10+ and Dolby Vision
  • HDCP 2.2/1.4 compliant
  • Downscales 4K to 1080p resolution
  • Supports Audio Return Channel (ARC)
  • Source Audio Extraction
  • Digital and Analog audio outputs
  • Features auto and manual source switching
  • Manually adjustable EDID
  • IR remote control and/or manual front panel control for switching

Specs

Input Ports4×HDMI Type A [19-pin female]
Output Ports2×HDMI Type A [19-pin female]; 1×L/R audio out [3.5mm Stereo Mini-jack]; 1×OPTICAL audio out [S/PDIF]
HDMI 2.0
HDCP 2.2 and HDCP 1.4
Video Bandwidth18 Gbps
Video ResolutionUp to 4K2K@50/60Hz (YCbCr 4:4:4), 4Kx2K@30Hz
HDMI Audio FormatsPCM 2.0/5.1/7.1CH, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD
Optical Audio FormatsPCM 2.0, Dolby Digital / Plus, DTS
Power SupplyInputAC100~240V 50/60Hz; OutputDC12V/1A



Dimensions

Size (W x H x D)9.9” x 0.8” x 4.1”
Weight1.36 lb.



Features
  • Allows up to 4 HDMI sources to be distributed simultaneously on 2 displays
  • Supports up to 4K@60Hz and 4:4:4 chroma sampling
  • Supports HDR10+ and Dolby Vision
  • HDCP 2.2/1.4 compliant
  • Downscales 4K to 1080p resolution
  • Supports Audio Return Channel (ARC)
  • Source Audio Extraction
  • Digital and Analog audio outputs
  • Features auto and manual source switching
  • Manually adjustable EDID
  • IR remote control and/or manual front panel control for switching
