| HDMI Compliance | HDMI Deep Color 30/36/48 bit color depth, Full 3D |
| HDCP Compliance | Yes |
| Video Bandwidth | 594 MHz |
| Video Support | 480i/480p/720p/1080i/1080p/4Kx2K @60 |
| Audio Support | Surround Sound (up to 7.1 ch) or stereo digital audio |
| Input TMDS Signal | 1.2 Volts (peak to peak) |
| Input DDC Signal | 5 Volts (peak to peak, TTL) |
| IR pass-thru | Full-duplex bi-directional |
| Input | (TX) 1xHDMI; (RX) 1xRJ45 + 2x3.5mm |
| Output | (TX) 1xRJ45 + 2x3.5mm; (RX) 1xHDMI |
| HDMI source control | Controllable via IR pass-through from RX to TX and from TX to RX with IR extenders or via CEC integrated |
| HDMI connector | Type A 19 pin female |
| RJ-45 connector | WE/SS 8P8C |
| LED indicators | Video lock yellow, Power, green |
| 3.5mm connector | (TX and RX) IR Receiver/ IR blaster |
