| HDMI Compliance | HDMI 1.3 |
| HDCP Compliance | HDCP 1.4 |
| Video Bandwidth | 6.75Gbps |
| Video Resolution | 1080p, 1080i, 720p, 720i, 480p, 480i, 1920×1080@60Hz, 1920×1200@60Hz (Maximum) |
| Color Space | RGB/YCbCr 4:4:4, YCbCr 4:2:2, YUV 4:2:0 |
| Color Depth | 8/10/12-bit (1080P60Hz) |
| Audio Formats | LPCM 2.0CH 32KHz/44.1KHz/48KHz |
| Transmitter Inputs | 1x HDMI Type A [19-pin female] |
| Transmitter Outputs | 1x IR OUT [3.5mm Stereo Mini-jack]; 2x WiFi OUT |
| [WiFi antenna] |
| Transmitter Control | 1x SERVICE [Micro USB, Update port] |
| Receiver Inputs | 1x IR IN [3.5mm Stereo Mini-jack]; 2x WiFi IN [WiFi |
| antenna] |
| Receiver Outputs | 1x HDMI Type A [19-pin female] |
| Receiver Control | 1x SERVICE [Micro USB, Update port] |
| HDMI in/out | 42 ft/15m |
