| Port Layout |
1 GbE RJ45: 32 (1G/100M/10M)
2.5 GbE RJ45: 16 (2.5G/1G/100M/10M)
10G SFP+: 4(10G/1G) |
| Redundancy |
DC Power Backup with UniFi RPS |
| Form Factor |
Rack mount (1U) |
| Switching Capacity |
224 Gbps |
| Total Non-Blocking Throughput |
112 Gbps |
| Forwarding Rate |
167 Mpps |
| Supported VLANs |
1,000 |
| MAC Address Table Size |
32,000 |
| IPv4 Static Routes |
256 |
| Packet Buffer Size |
2 MB |
| Access Lists |
IPv4: 128
MAC: 128 |
| Layer 3 Features |
DHCP Server (Local Networks)
DHCP Relay
Inter-VLAN Routing (Local Networks)
Static Routing (Local Networks) |
| Layer 2 Features |
LACP Port Aggregation
STP & RSTP
QoS (DSCP)
Pro AV Profiles (Play, Dante, Q-SYS, NDI, SDVoE, Shure, AES67, Crestron)
Advanced IGMP Configuration (Querier, Fast Leave, Router Port)
IGMP Snooping
802.1X Control
MAC-Based ACLs & Device Isolation
DHCP Snooping & Guarding
Egress Rate Limit
Flow Control
Storm Control
Multicast & Broadcast Rate Limiting
MAC Address Blocking
IP-Based ACLs & Network Isolation
MAC-Based Port Restriction
Port Isolation
Port Mirroring
Jumbo Frames
LLDP-MED
Voice VLAN
Loop Protection
Virtual Network Override |
| Max. Power Consumption |
100W |
| Power Method |
(1) Universal input, 100–240V AC, 50/60 Hz
(1) USP RPS DC input |
| Power Input Method |
AC input |
| Power Supply |
AC/DC, internal, 100W |
| Supported Voltage Range |
100–240V AC |
| Management |
Ethernet
AR |
| Heat Dissipation |
341.2 BTU/hr |
| Enclosure & Mount Material |
SGCC steel |
| LCM Display |
1.3" touchscreen |
| ESD Protection |
Air: ± 16kV, contact: ± 12kV |
| Ambient Operating Temperature |
-5 to 40° C (23 to 104° F) |
| Ambient Operating Humidity |
10 to 90% noncondensing |
| Etherlighting™ |
Ethernet
SFP+ |
| Certifications |
CE, FCC, IC, Anatel: 06373-24-08356 |
| UniFi Network |
Version 8.0.24 and later |
