| Audio Channel |
2.2.2ch |
| Audio Power Output |
10W + 10W + 10W + 10W + 10W + 10W + 5W + 5W |
| Speaker Position |
Front + Side + Top |
| Bass/Treble/Balance |
Balance |
| Speaker Type |
Acoustic Multi-Audio+ |
| Speaker Configuration |
Multiway Multi-amplifier connections (Tweeter x 2, Mid Range x 2, Subwoofer x 2, Beam Tweeter x 2) |
| Digital Audio Out (optical) format |
Two channel linear PCM, 48kHz 16bits, Dolby Audio, DTS |
|
| Display Type |
LCD Mini LED |
| Backlight Dimming Type |
Full Array Local Dimming |
| Screen Size |
75” (Also available in 65", 85") |
| Display Resolution (H x V, pixels) |
3840 x 2160 |
| Display Resolution |
QFHD |
| Aspect Ratio |
16:9 |
| Backlight Type |
Mini LED |
| RF (Terrestrial/Cable) Connection Inputs |
1(side) |
| HDMI Inputs |
4(4side) |
| Digital Audio Outputs |
1(side/hybrid with S-center speaker input) |
| USB Ports |
2(side) |
| Ethernet Inputs |
1(side) |
| RS-232C Inputs |
1(side) |
| Power Requirements (voltage) |
AC 120V for UL cUL AC 110-240V for other |
| Power Requirements (frequency) |
60Hz for UL cUL 50/60Hz for other |
| Rated Power Consumption |
451W |
