| Power supply |
110 - 240 V AC 50/60 Hz |
| Power consumption |
< 0.3 W |
| Power measurement (W) |
No |
| Max switching voltage |
AC: 240 V
DC: 30 V |
| Max switching current |
AC: 16 A per channel, 48 A total
DC: 16 A per channel, 48 A total |
| Overheating protection |
Yes |
| Long range network |
Distance (depends on local condition): Up to 80 m indoors (262 ft.) or up to 1000 m outdoors (3281 ft.)
Z-Wave® repeater: No
Z-Wave® frequency bands: 912 MHz |
| Mesh network |
Distance (depends on local condition): Up to 40 m indoors (131 ft.)
Z-Wave® repeater: Yes
Z-Wave® frequency bands: 908.4 MHz |
| CPU |
Z-Wave® S800 |
| Shell material |
Plastic |
| Mounting |
DIN rail |
| Screw terminals max torque |
0.4 Nm / 3.54 lbin |
| Conductor cross section |
0.5 to 2.5 mm² / 20 to 14 AWG (green connector) |
| Conductor stripped length |
6 to 7 mm / 0.24 to 0.28 in (green connector) |
| Ambient temperature |
-20°C to 40°C / -5°F to 105°F |
| Humidity |
30% to 70% RH |
| Max. altitude |
2000 m / 6562 ft. |
