| Power supply |
120 V AC 50/60 Hz |
| Power consumption |
< 0.3 W |
| Power measurement [W] |
Yes |
| Max. Power per channel |
1/3 hp |
| Max switching voltage AC |
120 V |
| Max switching current AC |
7 A per channel, 14 A total |
| Impulse voltage |
2500 V |
| Overheating protection |
Yes |
| Overcurrent protection |
Yes |
| Overvoltage category |
III |
| Type of action |
Type 1.B |
| Long range network |
Distance: Up to 80 m indoors (262 ft.) or up to 1000 m outdoors (3281 ft.) (depends on local condition)
Z-Wave® repeater: No
Z-Wave® frequency bands: 912 MHz |
| Mesh network |
Distance: Up to 40 m indoors (131 ft.) (depends on local condition)
Z-Wave® repeater: Yes
Z-Wave® frequency bands: 908.4 MHz |
| CPU |
Z-Wave® S800 |
| Purpose of control |
Operating |
| Construction of control |
Independently mounted |
| Mounting |
Flush mounting |
| Screw terminals max torque |
0.4 Nm / 3.5 lbin |
| Conductor cross section |
0.5 to 1.5 mm² / 20 to 16 |
| Conductor stripped length |
5 to 6 mm / 0.20 to 0.24 in |
| Shell material |
Plastic |
| Ambient working temperature |
-20 °C to 40 °C / -5 °F to 105 °F |
| Humidity |
30 % to 70 % RH |
| Max. altitude |
2000 m / 6562 ft. |
