| Touch Screen |
5-point capacitive |
| Screen resolution, px |
720x720 |
| Power supply |
100-240 V~, 50/60Hz |
| Power consumption |
< 5 W |
| USB TYPE-C power supply |
5V⎓, 1A |
| Speaker |
1 W |
| Max. switching voltage |
240 ~ |
| Max. switching current |
5 A |
| USB TYPE-C, voltage |
5 V⎓ |
| USB TYPE-C, current |
0.5 A |
| Light sensor |
Yes |
| Microphone |
Yes |
| Proximity sensor |
Yes |
| Wi-Fi |
Protocol: Wi-Fi 6 Dual Band
RF band: 2412 – 2472 MHz, 5150 – 5850 MHz
Max. RF power: < 20 dBm
Range: Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors (Depends on local conditions) |
| Bluetooth |
Protocol: 5.0
RF band: 2402 - 2480 MHz
Max. RF power: < 4 dBm
Range: Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors (Depends on local conditions) |
| CPU |
Rockchip RK3326-S Quad core Cortex-A35 1.5GHz |
| RAM |
1 GB |
| Flash |
8 GB |
| System |
Android 11 |
| Shell material |
Plastic, aluminum, glass |
| Mounting |
Wall box |
| Screw terminals max torque |
0.4 Nm / 3.5 lbin |
| Conductor cross section |
0.75 to 2.5 mm² / 18 to 14 AWG (solid, stranded, and bootlace ferrules) |
| Conductor stripped length |
6 to 7 mm / 0.24 to 0.28 inch |
| Schedules |
20 |
| Webhooks (URL actions) |
20 with 2 URLs per hook |
| Scripting |
No |
| MQTT |
Yes |
| Ambient working temperature |
-20 °C to 40 °C / -5 °F to 105 °F |
| Humidity |
30 % to 70 % RH |
| Max. altitude |
2000 m / 6562 ft |
