| Power supply |
110 - 240 V ̴ 50/60 Hz |
| Power consumption |
< 0.3 W |
| External protection |
10 A, tripping characteristic B or C, 6 kA interrupting rating, Energy limiting class 3 |
| Dimming type |
Trailing edge |
| Power measurement [W] |
Yes |
| Max. output power |
200 W |
| Overheating protection |
Yes |
| Overcurrent protection |
Yes |
| Overvoltage protection |
Yes |
| Radio |
Distance: Up to 40 m indoors (131 ft.) (depends on local condition)
Z-Wave® repeater: Yes
Z-Wave® frequency bands: 868.4 MHz |
| Maximum radio frequency power transmitted in frequency band(s) |
< 25 mW |
| CPU |
Z-Wave® S800 |
| Shell material |
Plastic |
| Mounting |
DIN rail |
| Screw terminals max torque |
0.4 Nm / 3.54 lbin |
| Conductor cross section |
0.5 to 2.5 mm² / 20 to 14 AWG (green connector)
0.5 to 1.5 mm² / 20 to 16 AWG (white connectors) (solid, stranded, and bootlace ferrules) |
| Conductor stripped length |
6 to 7 mm / 0.24 to 0.28 in (green connector)
5 to 6 mm / 0.20 to 0.24 in (white connectors) |
| Ambient working temperature |
-20 °C to 40 °C / -5 °F to 105 °F |
| Humidity |
30 % to 70 % RH |
| Max. altitude |
2000 m / 6562 ft |
