| Power supply |
110 - 240 V~ |
| Power consumption |
< 3 W |
| Neutral not needed |
No |
| 0-10V/1-10V voltage control type |
Current sourcing |
| External protection |
16 A, tripping characteristic B or C, 6 kA interrupting rating, Energy limiting class 3 |
| Max. switching voltage |
240 V~ |
| Max. switching current |
16 A |
| Voltmeter (AC) |
Yes |
| Ammeter (AC) |
Yes |
| Power and energy meters |
Active and apparent power
Active and apparent energy
Power factor
Fundamental active and fundamental reactive energy |
| Measurement data storage |
No |
| Internal-temperature sensor |
Yes |
| Wi-Fi |
Protocol: 802.11 b/g/n
RF band: 2412 - 2472 МHz
Max. RF power: < 20 dBm
Range: Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors (Depends on local conditions) |
| Bluetooth |
Protocol: 4.2
RF band: 2402 - 2480 MHz
Max. RF power: < 4 dBm
Range: Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors (Depends on local conditions) |
| CPU |
ESP32-D0WDQ6 |
| Clock frequency |
40 Mhz |
| Flash |
8 MB |
| Mounting |
DIN |
| Screw terminals max torque |
0.4 Nm / 3.54 lbin |
| Conductor cross section |
0.5 to 2.5 mm² / 20 to 14 AWG (green connectors) 0.5 to 1.5 mm² / 20 to 16 AWG (blue connectors) |
| Conductor stripped length |
6 to 7 mm / 0.24 to 0.28 in (green connector) 5 to 6 mm / 0.20 to 0.24 in (blue connectors) |
| Shell material |
Plastic |
| Schedules |
20 |
| Webhooks (URL actions) |
20 with 5 URLs per hook |
| Scripting |
Yes |
| MQTT |
Yes |
| Advanced schedules |
Yes |
| KVS (Key-Value Store) |
Yes |
| Ambient working temperature |
-20 °C to 40 °C / -5 °F to 105 °F |
| Humidity |
30 % to 70 % RH |
| Max. altitude |
2000 m / 6562 ft |
