| Power supply voltage |
AC: 110 - 240 V
DC: N/A |
| Power consumption |
< 3 W |
| Neutral not needed |
No |
| Max switching voltage |
AC: 240 V
DC: N/A |
| Max switching current |
AC: 16 A per channel, 25 A total
DC: N/A |
| Voltmeter (AC) |
Yes |
| Ammeter (AC) |
Yes |
| Screw terminals max torque |
0.4 Nm / 3.54 lbin |
| Conductor cross section |
0.5 to 2.5 mm² / 20 to 14 AWG (green connectors)
0.5 to 1.5 mm² / 20 to 16 AWG (blue connectors) |
| Conductor stripped length |
6 to 7 mm / 0.24 to 0.28 in (green connector)
5 to 6 mm / 0.20 to 0.24 in (blue connectors) |
| Internal-temperature sensor |
Yes |
| Mounting |
DIN rail |
| Shell material |
Plastic |
| Radio |
RF band: 2400 - 2495 MHz
Max. RF power: <20 dBm
Wi-Fi protocol: 802.11 b/g/n
Wi-Fi Range: Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors (Depends on local conditions)
Bluetooth Protocol: 4.2
Bluetooth Range: Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors (Depends on local conditions) |
| CPU |
ESP32-D0WDQ6 |
| Flash |
8 MB |
| Schedules |
20 |
| Webhooks (URL actions) |
20 with 5 URLs per hook |
| Scripting |
Yes |
| MQTT |
Yes |
| CoAP |
No |
| Ambient temperature |
-20°C to 40°C / -5°F to 105°F |
| Humidity |
30% to 70% RH |
| Max. altitude |
2000 m / 6562 ft |
