| Power supply |
220 - 240 V~ 50/60 Hz |
| Power consumption |
< 1 W |
| Max. switching voltage |
250 V~ |
| Rated output current |
16 A total between all 4 sockets |
| Max. switching current |
12 A per individual socket |
| Max. output power |
3680 W |
| Number of switching cycles |
10000 |
| Overvoltage category |
II |
| Duty-type |
S1 |
| Switch type |
One-way |
| Switch configuration |
SPNO (single-pole, normally-open) |
| Type of circuit disconnection |
Micro (µ) |
| Voltmeter (AC) |
Yes |
| Ammeter (AC) |
Yes |
| Power and energy meters |
Yes |
| Internal-temperature sensor |
Yes |
| Wi-Fi |
Protocol: 802.11 b/g/n/ax
RF band: 2412 - 2472 МHz
Max. RF power: < 20 dBm
Range: Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors (Depends on local conditions) |
| Bluetooth |
Protocol: 5.0
RF band: 2402 - 2480 MHz
Max. RF power: < 4 dBm
Range: Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors (Depends on local conditions) |
| Zigbee |
Protocol: 802.15.4
Zigbee repeater: Yes
RF bands: 2400 to 2483.5 MHz
Max. RF power: < 20 dBm
Range: Up to 100 m / 328 ft indoors and 300 meters / 984 ft outdoors (Depends on local conditions) |
| Shell material |
Plastic |
| Compatible sockets |
CEE 7/1, CEE 7/3 (Type F / Schuko) or CEE 7/5 (Type E) |
| Compatible plugs |
CEE 7/2, CEE 7/4 (Type F / Schuko), CEE 7/7, CEE 7/16 (Type C) or CEE 7/17 |
| CPU |
ESP-Shelly-C68F |
| Flash |
8 MB |
| Schedules |
20 |
| Webhooks (URL actions) |
20 with 5 URLs per hook |
| Scripting |
Yes |
| MQTT |
Yes |
| CoAP |
No |
| Ambient working temperature |
-20°C to 40°C / 5°F to 105°F |
| Humidity |
30% to 70% RH |
| Max. altitude |
2000 m / 6562 ft |
