| Power supply |
110-240 V~ |
| Power consumption |
< 1 W |
| External protection |
Tripping characteristic B or C, max. 16A max. rated current, min. 6 kA interrupting rating, energy limiting class 3 |
| Voltmeter (AC) |
110-240 V~ 50/60 Hz |
| Voltmeter accuracy |
±1% |
| Ammeter (AC) |
0 - 16A |
| Ammeter accuracy |
±1% |
| Power and energy meters |
Active power
Active energy |
| Measurement data storage |
At least 10 days of 1 min data resolution |
| Data export |
CSV for PQ recorded values
JSON format export through RPC |
| Max. measurement voltage |
240 V~ |
| Max. measurement current |
16 A |
| Max. measurement power |
3840 W |
| CPU |
ESP-Shelly-C68F |
| Flash |
8 MB |
| Schedules |
20 |
| Webhooks (URL actions) |
20 with 5 URLs per hook |
| Power measurement |
Yes |
| Scripting |
Yes |
| MQTT |
Yes |
| UDP |
Yes |
| Advanced schedules |
Yes |
| KVS (Key-Value Store) |
Yes |
| Wi-Fi |
Protocol: 802.11 b/g/n/ax
RF band: 2412 - 2472 MHz
Max. RF power: < 20 dBm
Range: Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors (Depends on local conditions) |
| Bluetooth |
Protocol: 5.0
RF band: 2402 - 2480 MHz
Max. RF power: < 4 dBm
Range: Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors (Depends on local conditions) |
| Zigbee |
Protocol: 802.15.4
RF bands: 2400 to 2483.5 MHz
Max. RF power: < 20 dBm
Range: Up to 100 m / 328 ft indoors and 300 meters / 984 ft outdoors (Depends on local conditions) |
| Mounting |
Wall console |
| Shell material |
Plastic |
| Shell color |
White |
| Screw terminals max torque |
0.4 Nm / 3.5 lbin |
| Ambient working temperature |
-20 °C to 40 °C / -5 °F to 105 °F |
| Humidity |
30 % to 70 % RH |
| Max. altitude |
2000 m / 6562 ft |
