| Power supply |
220-240 V~ 50 Hz |
| Power consumption |
< 1.5 W |
| Neutral not needed |
Yes |
| Min. load without neutral and without a Bypass |
20 W |
| Dimming type |
Trailing edge |
| External protection |
16 A, tripping characteristic B or C, 6 kA interrupting rating, Energy limiting class 3 |
| Short circuit protection |
Yes |
| Max. output power |
200 W |
| Voltmeter range (AC) |
180 V - 240 V |
| Voltmeter accuracy |
± 5 % (when used with neutral) |
| Ammeter range (AC) |
0 A - 3 A, |
| Ammeter accuracy |
± 5 % (when used with neutral) |
| Internal-temperature sensor |
Yes |
| Screw terminals max torque |
0.4 Nm / 3.5 lbin |
| Conductor cross section |
0.5 to 4 mm² / 20 to 11 AWG (solid, stranded, and bootlace ferrules) |
| Conductor stripped length |
5 to 6 mm / 0.20 to 0.24 in |
| Mounting |
In-wall |
| Shell material |
Plastic |
| Wi-Fi |
Protocol: 802.11 b/g/n
RF band: 2401 - 2483 МHz
Max. RF power: < 20 dBm
Range: Up to 50 m / 164 ft outdoors, up to 30 m / 98 ft indoors (depending on local conditions) |
| Bluetooth |
Protocol: 4.2 (BLE)
RF band: 2402 - 2480 MHz
Max. RF power: < 4 dBm
Range: Up to 30 m / 98 ft outdoors, up to 10 m / 33 ft indoors (depending on local conditions) |
| CPU |
ESP32 C3
STM32 G051 |
| Clock frequency |
ESP32 C3: 40 Mhz |
| Flash |
8 MB |
| Schedules |
20 |
| Webhooks (URL actions) |
20 with 5 URLs per hook |
| Scripting |
Yes |
| MQTT |
Yes |
| Advanced schedules |
Yes |
| KVS (Key-Value Store) |
Yes |
| Ambient temperature |
-20 °C to 40 °C / -5 °F to 105 °F |
| Humidity |
30 % to 70 % RH |
| Max. altitude |
2000 m / 6562 ft |
