| Power supply |
1x 3.6 V LISOC 14505 2700mAh battery |
| Battery life |
Up to 4 years |
| Measurement range |
200 mm - 5000 mm |
| Accuracy |
from 20 cm to 200 cm : +/- 2cm
above 200 cm: +/- 1% |
| Bluetooth |
Yes |
| Bluetooth Protocol |
5 |
| Bluetooth RF band |
2402 - 2480 MHz |
| Bluetooth Max. RF power |
<20 dBm |
| Bluetooth Range |
Up to 10 m / 33 ft indoors, 30 m / 100 ft outdoors (dependent on local conditions) |
| CPU |
Silicon Labs - EFR32MG27C140F768IM32 |
| Clock frequency |
38.4 Mhz |
| RAM |
64 kB |
| Flash |
768 kB |
| Encryption |
AES encryption (CCM mode) |
| Accelerometer |
Yes |
| Measure interval |
Valid range = 5 seconds to 300 seconds
Default - 30 seconds |
| Measurement ranges (7 types) |
Range 1 - Close (200mm-450mm)
Range 2 - Mid (300mm - 3500mm)
Range 3 - Close and Mid (200mm - 3500mm)
Range 4 - Far (2500mm - 5000mm)
Range 5 - Close (200mm-450mm) and Far (2500mm - 5000mm)
Range 6 - Mid and Far (300mm - 5000mm)
Range 7- Full range (200 mm - 5000 mm) |
| Ambient working temperature |
-20°C to 40°C / 5°F to 105°F |
| Humidity |
30% to 75% RH |
| Degree of protection |
IP64 |
