| Power supply |
220-240 V~ 50/60 Hz (between LA and N) |
| Power consumption |
< 2 W |
| External protection |
63 A, tripping characteristic B or C, 6 kA interrupting rating, Energy limiting class 3 |
| Internal-temperature sensor |
Yes |
| Voltmeters (RMS for each phase) |
220-240 V~ 50/60 Hz |
| Voltmeters accuracy |
better than ±1% |
| Ammeters (RMS via integrated CT for each phase) |
0 - 63 A (130 A saturation) |
| Ammeters accuracy |
±1 % (2 - 63 A), ±2 % (1 - 2 A), ±5 % (0 - 1 A) |
| Power and energy meters |
Active and apparent power
Active and apparent energy
Power factor
Fundamental active and fundamental reactive energy |
| No load threshold |
30 VA |
| Measurement data storage |
At least 7 days of 1 min data resolution |
| Data export |
CSV for PQ recorded values
JSON format export through RPC |
| Wi-Fi |
Protocol: 802.11 b/g/n
RF band: 2401 - 2483 МHz
Max. RF power: < 20 dBm
Range: Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors (Depends on local conditions) |
| Bluetooth |
Protocol: 4.2
RF band: 2400 - 2483.5 MHz
Max. RF power: < 4 dBm
Range: Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors (Depends on local conditions) |
| CPU |
ESP-Shelly-C38F |
| Flash |
8 MB |
| Conductor aperture |
Ø8 mm / Ø0.3 in |
| Mounting |
Above or under DIN-rail mounted circuit breakers |
| Shell material |
Plastic |
| Schedules |
20 |
| Webhooks (URL actions) |
20 with 5 URLs per hook |
| Scripting |
Yes |
| MQTT |
Yes |
| Ambient working temperature |
-20 °C to 40 °C / -5 °F to 105 °F |
| Humidity |
30 % to 70 % RH |
| Max. altitude |
2000 m / 6562 ft |
