| Power supply |
110-240 V~
24-30 V⎓ |
| Power consumption |
< 1 W |
| External protection |
Cable protection switch in accordance with EN60898-1 (tripping characteristic B or C, max. 16 A rated current, min. 6 kA interrupting rating, energy limiting class 3) |
| Max. switching voltage |
240 V~
30 V⎓ |
| Max. switching current |
16 A (240 V~)
10 A (30 V⎓) |
| Voltmeter (AC) |
Yes |
| Ammeter (AC) |
Yes |
| Internal-temperature sensor |
Yes |
| Screw terminals max torque |
0.4 Nm / 3.5 lbin |
| Conductor cross section |
0.5 to 4 mm² / 20 to 11 AWG (solid, stranded, and bootlace ferrules) |
| Conductor stripped length |
6 to 7 mm / 0.24 to 0.28 in |
| Mounting |
Wall console |
| Shell material |
Plastic |
| Wi-Fi |
Protocol: 802.11 b/g/n/ax
RF band: 2412 - 2472 МHz
Max. RF power: < 20 dBm
Range: Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors (Depends on local conditions) |
| Bluetooth |
Protocol: 5.0
RF band: 2402 - 2480 MHz
Max. RF power: < 4 dBm
Range: Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors (Depends on local conditions) |
| Zigbee |
Protocol: 802.15.4
Zigbee repeater: Yes
RF bands: 2400 - 2483.5 MHz
Max. RF power: < 20 dBm
Range: Up to 100 m / 328 ft indoors and 300 meters / 984 ft outdoors
(Depends on local conditions) |
| CPU |
ESP-Shelly-C68F |
| Flash |
8MB |
| Schedules |
20 |
| Webhooks (URL) actions |
20 with 5 URLs per hook |
| Scripting |
Yes |
| MQTT |
Yes |
| Ambient working temperature |
-20 °C to 40 °C / -5 °F to 105 °F |
| Humidity |
30 % to 70 % RH |
| Max. altitude |
2000 m / 6562 ft |
