| Power supply |
110-240 V~
24-48 V⎓
12 V⎓ |
| Power consumption |
< 1 W |
| External protection |
Cable protection switch in accordance with EN60898-1 (tripping characteristic B or C, max. 16 A rated current, min. 6 kA interrupting rating, energy limiting class 3) |
| Max. switching voltage |
240 V~
30 V⎓ |
| Max. switching current |
16 A/240 V~
10 A/30 V⎓ |
| Internal-temperature sensor |
Yes |
| Screw terminals max torque |
0.4 Nm / 3.5 lbin |
| Conductor cross section |
0.5 to 4 mm² / 20 to 11 AWG (solid, stranded, and bootlace ferrules) |
| Conductor stripped length |
6 to 7 mm / 0.24 to 0.28 in |
| Mounting |
Wall console |
| Shell material |
Plastic |
| Wi-Fi |
Protocol: 802.11 b/g/n/ax
RF band: 2401 - 2483 МHz
Max. RF power: < 20 dBm
Range: Up to 50 m / 164 ft outdoors, up to 30 m / 98 ft indoors (depending on local conditions) |
| Bluetooth |
Protocol: 5 (LE)
RF band: 2402 - 2480 MHz
Max. RF power: < 20 dBm
Range: Up to 30 m / 98 ft outdoors, up to 10 m / 33 ft indoors (depending on local conditions) |
| Zigbee |
Protocol: 3.0
Zigbee repeater: Yes
RF bands: 2405 - 2480 MHz
Max. RF power: < 20 dBm
Range: Up to 300 m / 984 ft outdoors, up to 100 m / 328 ft indoors (depending on local conditions) |
| CPU |
ESP-Shelly-C68F |
| Flash |
8MB |
| Schedules |
20 |
| Webhooks (URL) actions |
20 with 5 URLs per hook |
| Scripting |
Yes |
| MQTT |
Yes |
| Ambient working temperature |
-20 °C to 40 °C / -5 °F to 105 °F |
| Humidity |
30 % to 70 % RH |
| Max. altitude |
2000 m / 6562 ft |
