| Video Input | One, HDMI |
| HDBaseT Output | One, HDBaseT (PoH) (RJ45) |
| Audio | One, Stereo Audio (1 x 3.5mm jack) One in, One out, Digital audio (S/PDIF) |
| Control Signal | One, IR in, 3.5mm jack, One IR Out 3.5mm jack |
| Ports | One, RS-232 bidirectional, 3-pin phoenix connector |
| Ethernet | Two, RJ45 |
| USB Host | One, USB Type B |
| USB Device | Two, USB Type A |
| Input/Output Signal Type | HDMI with 4K@60Hz 4:2:0 (or 4K @30Hz when connected with VXP-82), HDCP 2.2, HDBT |
| Compliance | HDMI 2.0, HDCP 2.2 |
| Color Sampling | 4:4:4, 4:2:2, :2:0, resolutions with an asterisk * | 4:2:0 |
| Audio Formats | HDMI | PCM, Dolby TrueHD, Dolby Atmos, DTS-HD Master Audio, DTS:X, Line In/Out | PCM2.0, S/PDIF In/Out | Up to PCM5.1 |
| Max. Bandwidth | 10.2Gbit/s |
| Max. Pixel Clock | 297 MHz |
| HDBaseT Transmission Distance | 1080P@60Hz 3D, 4K@60Hz 4:2:0, 4K@30Hz 4:4:2 <330ft VXP-T and VXP-R used as stand-alone extender set | 1080p@60Hz <492ft |
| Control Method | RS232 Pass through, IR pass through, ethernet pass through, Bi-directional USB |
| Power Supply | 12VDC 2A (transmitter powers receiver via power over HDBaseT) |
