| HDBaseT Input | One, HDBaseT (PoH) (RJ45) |
| Video Output | One HDMI |
| Audio | One, Stereo Audio (1 x 3.5mm jack) One in, One out, Digital audio (S/PDIF) |
| Control Signal | One, IR in, 3.5mm jack, One IR out 3.5 mm jack |
| Ports | One, RS-232 bidirectional, 3-pin Phoenix connector |
| Ethernet | Two, RJ45 |
| USB Host | One, USB Type B |
| USB Device | Two, USB Type A |
| Input/Output Signal Type | HDMI with 4K@60Hz 4:2:0 (or 4K@30Hz when connected with VXP-82), HDCP 2.2, HDBT |
| Compliance | HDMI 2.0, HDCP 2.2 |
| Color Sampling | 4:4:4, 4:2:2, :2:0, Resolutions with an asterisk * | 4:2:0 |
| Audio Formats | HDMI | PCM, Dolby TrueHD, Dolby Atmos, DTS-HD Master Audio, DTS:X, Line/Out | PCM2.0, S/PDIF In/Out | Up to PCM5.1 |
| Max. Bandwidth | 10.2Gbit/s |
| Max.Pixel Clock | 297 MHz |
| Control Method | RS232 Pass through, IR pass through, Ethernet Pass through, Bi-directional USB |
