| AC Input Voltage | 100VAC ~ 240VAC, 15 watts |
| Digital Video Input | Four HDMI/MHL, One Display Port |
| HDBaseT Input | One, RJ45 |
| Analog Video Input | One VGA, female 15-pin (VGA, YPbPr, Composite Video) |
| Video Output | One HDMI |
| Output Resolution Range | Up to 4K @ 30Hz |
| Compliance | HDMI 1.4, HDCP 1.4 |
| Audio Line Input | Seven, Analog Stereo (3.5mm jack) |
| Audio Input Impedance | 20kΩ |
| Audio Output | Embedded, HDMI Digital Optical Audio, TOSLINK 8 Channel (7.1 Surround) Analog Audio, 4 x 3.5 mm Stereo Audio Jack |
| Frequency Response | 20Hz to 20kHz |
| Front Panel Control | 17 buttons for input select and menu |
| RS-232 | One, Bi-directional (9-pin D-sub connector) |
| Ethernet Port | One, 10/100Base-T (RJ45) |
