| AC Input Voltage | 110VAC~240VAC, 50~60Hz |
| Mounting | Rack Mount, 2 RU or free standing |
| Video Input | Three HDMI / One Display Port / Two VGA (female 15-pin) / Two HDBaseT (PoH) (RJ45) |
| Video Output | One HDMI / One HDBaseT (RJ45), 1920x1200<229ft (70m) |
| Resolution Range | 800x600@60Hz to 4Kx2K@60Hz |
| EDID Management | Built-in EDID data and manual EDID management |
| Compliance | Supports up to HDCP 2.2 |
| Audio Input | Two, Mono analog / Two, 3-pole 3.5mm / Mic line level |
| Audio Output | Two, stereo de-embedded |
| Phantom Power | Enable / Disable per channel |
| Analog Line Output with DSP | 2-channel stereo |
| Frequency Response | 20Hz to 20kHz < 3 dB |
| Infrared Output | six, 3.5mm / One, high output |
| Infrared Frequency Transmission Range | 15kHz-460kHz |
| Trigger Outputs | Three, 12 VDC, 100mA max each |
| Relays | Three, 5 amps @ 30 VDC |
| Sense Inputs | Three, 3-24 VDC |
| RS232 Ports | Two, Bidirectional control (RJ45) |
| Expansion Port | One, RJ45 connection |
| RTICOM Port | One, Zigbee, RJ45 connection |
| Ethernet Port | One, 10/100BaseT, RJ45-Ethernet pass through |
| LAN Port | One, 10/100BaseT, RJ45-WebGui access |
