| Video Inputs | 8 x HDMI Type A, 19-pin, female |
| Video Outputs | 1 x HDMI Type A, 19-pin, female, 8 x HDBaseT RJ45 connector |
| HDBaseT Transmission Distance | 1080p@50/60Hz ≤ 229ft (70m), 3840 x 2160 @50/60Hz 4:4:4 ≤ 131ft (40m) |
| Max. Bandwidth | 18Gbps |
| TCP/IP Control 1 x RJ45, female |
| RS-232 Serial Port | 1 x 3 Pin Phoenix Connector |
| IR Input | 9 x 3.5mm Stereo Jack |
| IR Output | 8 x 3.5mm Mono Jack |
| Mounting | Rack-Mountable, 1 U rack height, Rack Ears included or free standing |
