| Video Input | 1 x HDBaseT RJ45 Connector |
| Video Output | 1 x HDMI Type A, 19-pin, female |
| Audio Input | 1 x Toslink (S/PDIF) |
| Audio Output | 1 x Toslink (S/PDIF), 1 x 3.5mm L/R Analog Audio |
| HDBaseT Transmission Distance | 1080p@50/60Hz ≤ 229ft (70m), 3840 x 2160 @50/60Hz 4:4:4 ≤ 131ft (40m) |
| Max. Bandwidth | 18Gbps |
| RS-232 Serial Port | 1 x 3 Pin Phoenix Connector |
| IR Input | 1 x 3.5mm Stereo Jack |
| IR Output | 1 x 3.5mm Mono Jack |
| Mounting Kit | Included |
