| Power | +24 VDC |
| Mounting | Surface / wall mount |
| Audio Input | One Line Input Stereo (RCA jack), One Line Input Stereo (3.5 mm jack) |
| Microphone Input | One balanced/unbalanced (3-pin Phoenix Connector), Switchable Line / 48V Phantom Power |
| Input Impedance | >10K Ohms |
| Audio Output | One Stereo Speaker Output (4-pin terminal block), One Loop Output (3.5 mm jack) |
| Rated Output Power | 2 x 20 Watts @ 4 Ohms / 1 x 40 Watts bridged @ 8 Ohms |
| Speaker Impedance | 4 to 8 Ohms |
| Frequency Response | 20Hz to 20KHz |
| Bandwidth | 20Hz to 25Khz |
| Signal-to-Noise Ratio | 80dB at maximum output |
| Channel Separation | >75dB @ 20Hz to 20Khz |
| Voltage Gain | 32dB |
| CMRR | >70dB @ 20Hz~20KHz |
| Total Harmonic Distortion + Noise @ 1KHz | 1% at nominal level |
| Total Harmonic Distortion + Noise @ 20KHz | 0.3% at nominal level |
| Front Panel Control | 5 Buttons for Input Select, Volume and EQ |
| RS232 Control | One, Bidirectional control (3-pin Phoenix Connector) |
