| Power | +9VDC to +16VDC, 350mA max |
| Power Management | Adjustable backlight brightness, Ambient light sensor |
| Display | Color OLED with 65K colors |
| Display Size | 1.2in (30.5mm) diagonal, 128w x 96h pixels |
| Backlight | Blue/Red LED |
| Infrared Output | Through control port, 200mA output* Drives up to 1000 ft (300 m) of wire |
| Ethernet Port | 10/100 Base-T |
| Device Capability | Total number of devices is limited only by memory |
| Macro Capability | Unlimited steps in a single macro, Total number of macros is limited only by memory |
| Communications | USB programming port, Ethernet |
| Enclosure | Formed steel, black powder coat finish |
| Installation Cut-Out (H x W) | 2.85” x 1.78” |
| Total Depth in Wall | 0.75” plus cables |
