| HDMI Compliance | HDMI 2.0b |
| HDCP Compliance | HDCP 2.2 and HDCP 1.4 |
| Video Resolutions | Up to 4K@60Hz (YUV4:4:4), 4K@30Hz, 1080P@120Hz, and 1080P 3D@60HzSound Channel |
| Color Space | RGB, YCbCr 4:4:4, YCbCr 4:2:2 |
| Color Depth | 10-bit, 12-bit |
| HDMI Audio Formats (Pass-through) | LPCM 2/5.1/7.1CH, Dolby Digital, DTS 5.1, Dolby Digital+, Dolby TrueHD, DTS-HD Master Audio, Dolby Atmos, DTS:X |
| Optical Audio Formats | LPCM 2CH, Dolby Digital 2/5.1 ch, DTS 2/5.1ch |
| L/R Audio Formats | Analog Stereo 2ch |
| ESD Protection | Human body model — ±8kV (airgap discharge) & ±4kV (contact discharge) |
| Inputs | 1x HDMI Type A [19-pin female] |
| Outputs | 1x HDMI Type A [19-pin female]; 1x L/R Audio Out [RCA]; 1x Optical Out [S/PDIF] |
| Housing | Metal Enclosure |
