| Resting Voltage (Charge Voltage Dependent) | 13.1V-13.4V (Temp. and S.O.C dependent) |
| Float/Maintenance Charging Voltage | 14.2V |
| Max Charging Voltage | 14.8V |
| Minimum Charging Voltage | 13.6V |
| Capacity (Ah) | 56 |
| Capacity (Pb Eq) | 224 |
| Cell Chemistry | LifePo4 |
| Cell Life Cycles | 2,000 (80% DOD) |
| Craking Amps (CA) | 2,900 |
| Cold Craking Amps (CCA) | 2,100 |
| Nominal Operating Temperature Range | Up to 140F |
| Terminal Bolt Size | M8-125 |
| Terminal Orientation | Positive Left |
| Balance Board Installed | Yes |
| Battery Management System Installed (BMS) | No |
| RMS Wattage (Alternator size dependent) | 10,000W-13,000W (14.8V input voltage) |
| Max Burst Wattage (Alternator Size Dependent) | 16,000W (14.8V Input Voltage) |
| RMS Amperage Output (Stand alone for 30 seconds) | 750A (Starting at 14.8V) |
| Max Burst Amperage Output (Stand alone for 10 seconds) | 950A (starting at 14.8V) |
| Recommended Charging/Input Current | 250A |
| Maximum Charging/Input Current | 450A (charging above 450A shortens life cycle) |
| Warranty | Each battery comes with a 3-year manufacture defect full replacement warranty. |
