| Resting Voltage (Charge Voltage Dependent) | 12-16V |
| Float/Maintenance Charging Voltage | 14.2V |
| Max Charging Voltage | 16V |
| Minimum Charging Voltage | 10V |
| Capacity (Ah) | 30AH |
| Capacity (Pb Eq) | 110Pb Eq |
| Cell Chemistry | SIB |
| Cell Life Cycles | 4,000 (80% DOD) |
| Cranking Amps (CA) | 1,500 |
| Cold Cranking Amps (CCA) | 1,125 |
| Nominal Operating Temperature Range | 14F-140F |
| Terminal Bolt Size | M6-1.0 |
| Terminal Orientation | Left Positive |
| Balance Board Installed | Yes |
| Battery Management System Installed (BMS) | No |
| RMS Wattage (Installed with 100A stock alternator) | 4,000W-5,500W (14.6V Input Voltage) |
| Max Burst Wattage (Installed with 100A Alternator) | 6,000W (14.6V Input Voltage) |
| RMS Amperage Output (Stand alone for 30 seconds) | 300A (Starting at 14.6V) |
| Max Burst Amperage Output (Stand alone for 10 seconds) | 360A (Starting at 14.6V) |
| Recommended Charging/Input Current (Standard Voltage) | 250A |
| Maximum Charging/Input Current | 300A (Charging above 300A shortens the life cycle) |
| RMS Wattage (installed with 250A H/O alternator) | 6,000W-8,000W (16V input voltage) |
| Max Burst Wattage (installed with 250A H/O alternator) | 10,000W (16V input voltage) |
| RMS Amperage (stand alone for 30 seconds) | 450A (starting at 16V) |
| Max Burst Amperage (stand alone for 10 seconds) | 600A (starting at 16V) |
| Warranty | Each battery comes with a 3-year manufacture defect full replacement warranty. |
