| IEEE 802.3af (Power over Ethernet) | |
| IEEE 802.3at (High-Power PoE+ Power over Ethernet) | |
| IEEE 802.3 (10Base-T Ethernet) | |
| IEEE 802.3ab (Gigabit Ethernet) | |
| IEEE 802.3u (100Base-TX Fast Ethernet) | |
| One RJ45 10/100/1000 Mbps input port for 48 V IEEE 802.3af/at-compliant signal | |
| One RJ45 10/100/1000 Mbps PoE output port | |
| Certifications | FCC Class A, CE |
| Max PD output power | 25 W max |
| Max Power consumption" 4 W | |
| Input power | IEEE 802.3af/at compliant PSE |
| PoE Pinout Input | | IEEE Alternative A (pairs 1/2 and 3/6) | | IEEE Alternative B (pairs 4/5 and 7/8) | |
|
| PoE Pinout Output | | IEEE Alternative A (pairs 1/2 and 3/6) |
|
