| Main Processor | Multi-core embedded processor |
| Operating System | Embedded LINUX, ICR 4.0 |
| Display Interface | 1 HDMI, 1 VGA |
| OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Display Split | 1st Screen | 1/4/8/9/16, 2nd Screen | 1/4/8/9 /16 |
| Intelligent Motion Detect (iMD):4 channels (AI by Recorder) or 8 channels (AI by Camera) |
| Supported Camera Types | IP |
| Audio Compression | G.711a; G.711u; PCM; G726 |
| Two-way talk supported |
| Record Compression | Smart H.265+; H.265; Smart H.264+; H.264; MJPEG |
| Internal HDD | 2 SATA III Ports, up to 16 TB capacity for each HDD |
| HDD Mode | Redundancy |
| Ethernet | 1x (10/100/1000 Mbps Ethernet port, RJ-45) |
| Compatibility | ONVIF 22.06 (Profile T; Profile S; Profile G); CGI; SDK |
| Web Viewer | Chrome, IE 9 or later, Edge, Safari, Firefox |
| PoE | 8 ports, 10/100 Mbps, IEEE 802.3 af/at; Bridge Mode Supported |
| USB | 2 (1 front USB 2.0 port, 1 rear USB 2.0 port) |
| Power Supply | 100–240 VAC, 47-63 Hz |
| Power Consumption | Total output of NVR is <10 W (without HDD) Total output power of PoE is 130W, and the maximum output power of a single port is 25.5W |
| Total POE Budget | Total output power of PoE is 130W, the maximum output power of a single port is 25.5W |
| Operating Conditions | 14 °F to +131 °F |
| Operating Humidity | 10%–93% (RH) |
