| Main Processor | Multi-core embedded processor |
| Operating System | Embedded LINUX, ICR 4.0 |
| Max IP Channels | 64 channels (up to 32MP) |
| Video Compression | Smart H.265+/H.265/Smart H.264+/H.264/MJPEG |
| Image Resolution | 32 MP; 24 MP; 16 MP; 12 MP; 8 MP; 5 MP; 4MP; 1080p; 720p | D1 |
| Record Mode | Manual; alarm; motion detection; scheduled |
| Record Interval | 1~120 min (default | 60 min), Pre-record | 1~30 sec, Post-record | 10~300 sec |
| Audio Interface | 1 input, 2 output (RCA) |
| Two-way Talk | Supported |
| Audio Compression | G.711a; G.711u; PCM; G726 |
| Display Interface | 2 x VGA, 4 x HDMI video output |
| Main Screen Display Split | 1/4/8/9/16/25/36/64 |
| Sub Screen Display Split | 1/4/8/9/16/25/36 |
| OSD | Camera Title, Time, Video Loss, Camera lock, Motion detection, recording |
| Multi-channel Playback | Up to 16 channels |
| Record Mode | Manual, alarm, motion detection, scheduled |
| Backup Mode | Portable hard drive, eSATA disk, burner, USB device and network |
| Alarm Input | 16 channel |
| Alarm Output | 8 channel |
| General Alarm | Motion detection, video tampering, video loss, scene changing, PIR alarm, IPC external alarm |
| Anomaly Alarm | Camera offline, storage error, disk full, IP conflict, MAC conflict, login lock, abnormal behavior of fan |
| Intelligent Alarm | Face detection, perimeter protection, face recognition, video metadata (human, motor vehicles, and non-motor vehicles); iMD stereo analysis, crowd disruption, people counting, ANPR, vehicle density, heat map |
| Alarm Linkage | Record, snapshot (panoramic); local alarm output; IPC external, alarm output, access controller, audio, buzzer, log, preset, email |
| Ethernet | 2 RJ-45 ports (10/100/1000Mbps) |
| Smart Phone | Android, iOS iPhone |
| Browser Capability | Chrome, IE 9 or later, Edge, Safari, Firefox |
| Internal HDD | 8 SATA III Ports, Up to 16 TB capacity for each HDD |
| eSATA | 1 eSATA |
| RAID | RAID 0, 1, 5, 6, 10 Support |
| USB | 4 (2 front USB 2.0 ports, 2 rear USB 3.0 ports) |
| RS232 | 1 port |
| RS485 | 2 (1 port for half-duplex serial communication, 1 port for full-duplex serial communication) |
| Power Supply | 100-240 VAC, 50/60Hz |
| Power Consumption | |
| Installation Type | Rack Mountable |
