| Multi-core embedded processor |
| Embedded LINUX, ICR 4.0 |
| Display Interface | 2x VGA, 4x HDMI video output |
| Display Split | Main screen | 1/4/8/9/16/25/36, Sub screen | 1/4/8/9/16/25/36 |
| IVS | Tripwire & intrusion- 10 IVS rules for each channel, 50 objects max | 24 channels (AI by Recorder) or 32 channels (AI by Camera) |
| Intelligent Motion Detect (iMD) | 32 channels (AI by Recorder) or 32 channels (AI by Camera) |
| Supported Camera Types | IP |
| Audio Compression | G.711a; G.711u; PCM; G726 |
| Two-way talk supported |
| Record Compression | Smart H.265+/H.265/ SmartH.264+/H.264/MJPEG |
| Record Resolution:pre;"> 32 MP; 24 MP; 16 MP; 12 MP; 8 MP; 5 MP; 4 MP; 1080p; 720p; D1 |
| Incoming Bandwidth | 1024 Mbps (AI by Camera), 512 Mbps (AI by NVR/ Object Search) |
| Internal HDD:pre;"> 8 SATA III Ports, up to 16 TB capacity for each HDD |
| HDD Mode | Single, RAID 0,1,5,6,10 |
| Ethernet | 2 RJ-45 Ports (10/100/1000Mbps) |
| Compatibility | ONVIF (Profile S/profile T/Profile G); CGI; SDK |
| Web Viewer | Chrome, IE 9 or later, Edge, Safari, Firefox |
| USB | 4 (2 front USB 2.0 ports, 2 rear USB 3.0 ports) |
| Power Supply | 100–240 VAC, 50/60 Hz |
| Power Consumption | ≤ 18 W (without HDD) |
