| Main Processor | Industrial-grade embedded processor |
| Operating System | Embedded LINUX |
| Display Interface | 1 HDMI, 1 VGA (Configurable simultaneous/ heterogeneous video sources output for VGA and HDMI) |
| OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Display Split | 1st Screen | 1/4/9/16, 2nd Screen | 1/4/9 /16 |
| Intelligent Motion Detect (iMD) | 4 channels (AI by Recorder) or 8 channels (AI by Camera) |
| Supported Camera Types | IP |
| Audio Compression | G.711A/G.711U/PCM/G726 |
| Two-way talk supported |
| Record Compression | Smart H.265+; H.265; Smart H.264+; H.264; MJPEG |
| Internal HDD | 2 SATA III Ports, up to 16 TB capacity for each HDD |
| HDD Mode | Single |
| Ethernet | 1x (10/100/1000 Mbps Ethernet port, RJ-45) |
| Compatibility | ONVIF 22.06 (Profile T; Profile S; Profile G); CGI; SDK |
| Web Viewer | Chrome, IE 9 or later, Edge, Safari, Firefox |
| PoE | 16 ports (IEEE802.3at/af); Bridge Mode supported |
| USB | 2 ports (1 USB2.0, 1 USB3.0) |
| Power Supply | 100–240 VAC, 47-63 Hz (130W Max) |
| Power Consumption | <10W (without HDD) |
| Total POE Budget | Total output of NVR is <10 W (without HDD) Total output power of PoE is 130W, the maximum output power of a single port is 25.5W |
| Operating Conditions | 14 °F to +131 °F |
| Operating Humidity | 10%–93% (RH) |
