| Video Codec | Proprietary Codec based on M-JPEG |
| Audio Codec | Proprietary Codec |
| Latency | 16ms@60Hz |
| Streaming Protocols | TCP, UDP, IP, IGMP-V2 |
| Copy Protection | HDCP 2.2 and earlier |
| Signal Type | DVI 1.0 (ingested, outputs as HDMI), HDMI 2.0b |
| Video Resolution | 720p@50/60Hz; 1080p@24, 50&60Hz; 4K@50/60Hz 4:4:4; 4K@30Hz 4:4:4; 4K@60Hz 4:2:0; 4:2:2 4K@24Hz 4:2:0/4:2:2 (ultrawide support) |
| Bit Depth per Color | 1080p 8-,10-,12-bit, 4K 8-,10-,12-bit |
| Audio Format (end to end) | PCM 2, 5.1, 7.1 Channel, Dolby Digital 5.1 Channel, Dolby Digital Plus, DTS 5.1 Channel, DTS-ES, DTS-HD High Resolution, DTS-HD Master Audio, Dolby Atmos |
| Embedded Audio | Stereo Analog Audio (3.5mm jack) |
| USB | HID-Compliant |
| HDMI | HDCP 2.2, EDID Management, CEC |
| Ethernet | (1) x female RJ45, PoE |
| HDMI | (1) x HDMI Type A 19-pin, female, one HDMI input |
| Audio | (1) x 3.5mm mini stereo jack, VGA Audio input |
| RS232 | (1) x 3.5mm female jack |
| USB | (1) x USB 2.0 Type-B for USB Keyboard/Mouse Extension / (1) x USB-C for MXnet service / (1) x USB-C for input |
| Ethernet Distance | 330 feet over CAT5e and above |
| Max Power Consumption | 6.7W |
| PoE | IEEE 802.3af (15.4W) |
