| Video Codec | Proprietary codec based on M-JPEG |
| Audio Codec | Proprietary codec |
| Latency | 16ms @ 60Hz |
| Streaming Protocols | TCP, UDP, IP, IGMP-V2, DANTE |
| Copy Protection | HDCP 2.2 and earlier |
| Signal Type | DVI 1.0 (ingested, outputs as HDMI), HDMI 2.0b |
| Video Resolution | 720p@50/60Hz; 1080p@24, 50&60Hz; 4K@30Hz |
| Chroma Subsampling | 4:4:4, 4:2:2, 4:2:0 (compresses to RGB output) RGB |
| Bit Depth per Color | 1080p (8-, 10-bit), 4K (8-, 10-bit) (compresses to 8-bit output) |
| Visually Lossless | 1080p@60Hz SDR RGB (8-bit), 4K@30Hz SDR RGB (8-bit) |
| Audio Format (end to end) | PCM 2, 5.1, 7.1 Channel, Dolby Digital 5.1 Channel, Dolby Digital Plus, DTS 5.1 Channel, DTS-ES, DTS-HD High Resolution |
| Audio Format (HDMI Loopout) | Same end to end, with the addition of Dolby MAT 8ch |
| Embedded Audio | Stereo Analog Audio (3.5mm jack) |
| De-Embedded Audio | Balanced stereo analog audio (5-pin phoenix) |
| Ethernet | (2) x female RJ45, PoE, one for MXnet signal transmission, one for Dante signal transmission |
| SFP | (1) x SFP Slot |
| HDMI | (2) x HDMI Type A 19-pin, female, one HDMI input, one HDMI loop out |
| Audio | (1) x 5-pin terminal block, balanced L/R audio out / (1) x 3.5mm mini stereo jack, audio in |
| IR | (1) x 3.5mm mini-stereo jack (IR-PASS) / (1) x 3.5mm mini stereo jack (IR-EYE) / (1) x 3.5mm mini stereo jack (IR-OUT) |
| RS232 | (1) x 3-pin terminal block |
| USB | (1) x USB 2.0 Type-B for USB extension and KVM / (1) x USB Micro for MXnet service |
| Ethernet Distance | 330feet over CAT5e and above |
| SFP and Fiber Distance | 1000BASE-SX SFP Transceiver Module (MMF, 850nm, 550m, LC, DOM) 1000BASE-LX/LH SFP 1310nm 10km transceiver module |
| Max Power Consumption | 7.4W |
| PoE | IEEE 802.3af (15.4W) |
| Power Supply Unit | Input-AC 120-240V-50/60Hz 0.8A / Output-DC 12V 2A |
