| Video Resolutions | Up to 4K60 4:2:0 & 4K30 4:4:4 |
| VESA Resolutions | Up to 2560x2048 (QSXGA) |
| HDR formats/Resolutions | 4K24 4:2:2 12 bit, 4K24 4:2:0 10 bit |
| Audio Formats Supported | HDMI PCM 2.0 Ch, LPCM 5.1 & 7.1, Dolby Digtal, DTS 5.1, Dolby Digital Plus, |
| Dolby TrueHD, DTS-HD Master Audio, DTS-X, Dolby Atmos |
| HDMI Lead IN/OUT (4k60 4:4:4) | Up to 50 Feet (Using Bullet train HDMI) |
| HDMI Lead IN/OUT (W/ AOC Cable) (4k60 4:4:4) | Up to 2130 Feet (Using Bullet Train AOC) |
| HDBaseT (CAT) Distance 1080p | 100m (330 feet) (With CAT 6a/7) |
| HDBaseT (CAT) Distance4k & HDR | 70m (230 feet) (with cat6a/7) |
| HDMI (input) | Type A |
| HDBaseT (INPUT) | Rj45 |
| Audio (Extracted Digital) | TOSLINK |
| Audio (Extracted Analog) | Balanced L/R Audio (5 PIN Terminal Block) |
| IR | 3.5mm IR IN/OUT and IR Window on the front |
| RS232 | 3 PIN Terminal Block |
| Ports | LAN, RS232, IR Window |
