| Video Resolutions | Up to 4K 60Hz 4:4:4 |
| VESA Resolutions | Up to DCI 4K (4096x2160) |
| HDR Formats/Resolutions | 420, 422, 444 (10 and 12 Deep Color) HDR10, HDR10+, Dolby Vision, HLG |
| Color Space YUV (Component), RGB (CSC | Rec. 601, Rec. 709, BT2020, DCI, P3 D6500) |
| Chroma Subsampling | 4:4:4, 4:2:2, 4:2:0 Supported |
| Deep Color | Up to 16 bit (1080), Up to 12 bit (4K) |
| Audio Formats Supported | HDMI PCM 2.0 Ch, LPCM 5.1 & 7.1, Dolby Digital, DTS 5.1, Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio, DTS-X, Dolby Atmos |
| Extracted Audio | 2ch (3 Pin Terminal Block, Unbalanced) Digital (Toslink and SPDIF) |
| Compatible Receivers: AC-EX70-UHD-R, AC-EX70-444-RNE |
| Bandwidth | 18 Gbps |
| HDCP 2.2 and Earlier |
| Ports | LAN, RS232, IR, Micro USB |
| HDMI (TX & RX) | Type A |
| HDBaseT | RJ45 W/ POH for HDBaseT Receivers |
| IR (TX & RX) | 3.5mm Stereo |
| RS232 | 3 Pin Terminal Block |
| Power | 2 Pin Terminal Block |
| Power Consumption (Total) 60 watts max |
