| Signal Type | DVI 1.0, HDMI 2.0b |
| HDR Format | HDR 10, HLG, Dolby Vision @30Hz |
| Chroma Subsampling | 4:4:4, 4:2:2, 4:2:0 |
| Bit Depth per Color | 1080P (16Bit), 4K (10, 12 Bit) |
| Embedded Audio | Stereo Analog Audio |
| De-Embedded Audio | Stereo Analog Audio |
| Ethernet | (1) x female RJ-45, PoE |
| SFP | (1) x SFP Slot |
| HDMI | (1) x HDMI Type A 19-pin, female, HDMI output |
| Audio | (1) x Toslink Audio input / (1) x 3.5 mm mini stereo jack, Audio out |
| IR | (3) x 3.5mm mini-stereo jack, one IR-Pass, one IR-EYE, one IR-out |
| RS232 | (1) x 3 pin terminal block |
| USB | (2) x USB 2.0 Type-A for USB extension and KVM / (1) x USB Type-C for MXNET service |
| Ethernet Distance | 330 feet over CAT5e and above |
| SFP and Fiber | 1000BASE-SX SFP transceiver module (MMF, 850nm, 550m, LC, DOM) 1000BASE-LX/LH SFP 1310nm 10km transceiver module |
| Max Power Consumption | 6.5W |
| PoE (Power over Ethernet) | IEEE 802.3af (15.4W) |
| Power Supply Unit | Input-AC 120-240V-50/60Hz 0.8A / Output-DC 12V 2A |
