| Video Resolution | Up to 4K 60Hz 4:4:4 |
| Vesa Resolution | Up to DCI 4k (4096x2160) 5k (Up to 5120x3200) |
| Audio Formats Supported HDMI | PCM 2.0 CH, LPCM 5.1 & 7.1, Dolby Digital, DTS 5.1, Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio, DTS-X, Dolby Atmos |
| Audio Formats Supported Extracted (2CH) | PCM 2 CH |
| HDMI In/Out (up to 4K60 4:4:4) | Up to 50 Feet (Bullet Train HDMI) |
| HDMI In/Out (w/ AOC Cable) (up to 4K60 4:4:4) | Up to 130 Feet (w/ Bullet Train AOC) |
| Bandwidth | 18Gbps |
| HDCP 2.2 and Earlier |
| HDMI (Input) | Type A |
| LAN | RJ45 w/ Web Interface/ Control |
| Audio (Extracted Analog) | 5 pin terminal block (balanced) |
| IR RX | Window Only (Remote Included) |
| RS2323 | PIN Terminal Block |
| Ports | LAN, RS232, IR Window |
| LAN WebOS | Yes |
| Power Consumption | 6 Watts max |
| Power Supply | Input | AC 100-240V~50/60HZ, Output | DC 12V 2A |
