| Video Resolution | Up to 4K 60Hz 4:4:4 |
| Vesa Resolution | Up to DCI 4K (4096x2160) |
| HDR Formats/Resolution | 420, 422, 444 (10 and 12 Deep Color), HDR10, HDR10+, HLG |
| Audio Formats Supported HDMI | PCM 2.0 CH, LPCM 5.1 & 7.1, Dolby Digital, DTS 5.1, Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio, DTS-X, Dolby Atmos |
| Audio Formats Supported Extracted (2CH port) | PCM 2.0 Ch (no downmix) |
| HDBaseT (CAT) Distance (4K) | 70M (230 Feet) |
| HDBaseT (CAT) Distance (Full HD) | 100M (328 Feet) |
| HDMI Lead In/Out (up to 4K60 4:4:4) | Up to 50 Feet (Bullet Train HDMI) |
| HDMI Lead In/Out (w/ AOC Cable) (up to 4K60 4:4:4) | Up to 130 Feet (w/ Bullet Train AOC) |
| Bandwidth | 18 gbps (w/ITC) |
| HDCP 2.2 and earlier |
| HDMI (TX&RX) | Type A |
| Audio (Extracted Analog) (TX & RX) | 3 pin terminal block (unbalanced) |
| IR Tx (TX & RX) | 3.5mm Mono (2 Conductor) |
| IR Rx (TX & RX) | 3.5mm Stereo (3 Conductor) |
| RS-232 (TX & RX) | 3 pin terminal block |
| Power (TX & RX) | 2 pin terminal block |
| Ethernet | 2 RJ45 Connectors |
| Power Consumption | 9 Watts max |
| Power Supply | Input | AC 100-240V~50/60HZ, Output | DC 48V 0.5A (wall version) |
