| Video Resolutions | Up to 4K 60Hz 4:2:0 and 4K30 4:4:4 |
| VESA Resolutions | Up to 2560x2048 (QSXGA) |
| HDR Formats/Resolutions | 4K24 4:2:2 12BIT, 4K24 4:2:0 10BIT |
| Color Space | YUV (component), RGB (CSC | Rec. 601, Rec. 709, BT2020, DCI, P3 D6500) |
| Chroma Subsampling | 4:4:4, 4:2:2, 4:2:0 Supported |
| Deep Color | Up to 16 bit (1080) up to 12 bit (4K) |
| Audio Formats Supported HDMI | PCM 2.0 Ch, LPCM 5.1 and 7.1, Dolby Digital, DTS 5.1, Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio, DTS-X, Dolby Atmos |
| HDBaseT Distance (4K and HDR) | 131 feet (Cat6a) |
| HDBaseT Distance (Full HD) | 230 feet (Cat6a) |
| HDMI Lead In/Out | Up to 50 feet (using bullet train HDMI) |
| HDMI Lead In/Out (w/ AOC Cable) | Up to 130 feet (using bullet train AOC) |
| Bandwidth | 10.2 Gbps |
| CEC | Yes |
| HDCP | HDCP 2.2 and earlier |
| HDMI (TX and RX) | Type A |
| HDBaseT | RJ45 with PoH for HDBaseT Receivers |
| IR RX | 3.5mm Stereo (3 conductor) |
| IR Out and I-Pass | 3.5mm mono (2 conductor) |
| RS232 | 3.5mm Stereo (3 conductor) |
| Power Consumption (Total) | 7.5 watts max |
| Power Supply (Matrix) | Input-AC 100-240V~50/60Hz / Output-DC 48V .5A |
